Lumatek: 30W UV Auxiliary Light LED Bar

Lumatek 30W UV Auxiliary Light LED Bar

The Lumatek 30W UV Supplemental LED Bar offers a complementary light spectrum for growers looking to improve quality by incorporating UV output during the flowering phase. Designed to fit directly onto the popular Lumatek Zeus LED fixtures, this unit features an integrated power supply and can also be daisy-chained.

ITEMS INCLUDED:
1 x 30 W UV auxiliary light LED bar
2 x stainless steel hooks

ITEMS SOLD SEPARATELY:
Power cable (LUMM0032)
Daisy chain cable for UV bar (LUMM0033)

Note : Each Lumatek Zeus LED requires two units of the 30W UV bar (LEDL09) with one power cable (KAB15) and one daisy-chain cable (KAB16) for each pair of UV bars. Except for the Zeus 1000W Pro , three UV bars with one power cable and two daisy-chain cables are required.

Manufacturer's recommended coverage:

Lumatek's additional 30W UV LED bar is designed to fit directly into the Zeus fixtures. To ensure you achieve the best light distribution across the canopy, Lumatek recommends:

Integrate at least 2 units of a 30W UV auxiliary light LED bar with:

• ZEUS 465 W 2.6 | 1.2 x 1.2 m footprint
• ZEUS 600 W 2.6 | 1.4 x 1.4 m footprint
• ZEUS 465W PRO 2.9 | 1.2 x 1.2 m footprint
• ZEUS 600W PRO 2.9 | 1.4 x 1.4 m footprint
• ZEUS 1000W Xtreme CO2 | 1.5 x 1.5 m footprint with CO2 surcharge

FEATURES
- Increase in raw material content by 30%
- Control mold growth
- Reduce the need for chemical interventions
- Extends the shelf life of plants
- Top Bin LED UV chips
- Can be attached to all Lumatek Zeus full spectrum LED series
- Flexible hanging brackets
- Plug and Play: internal LED driver
- Daisy chain connectivity
- Passive cooling
- IP65
- Power cable (4 m) and daisy chain cable (1.5 m) sold separately

IMPORTANT SPECIFICATIONS:
PRODUCT CODE: LUMLED013
UV-B (280–315 NM): 100 mW
UV-A (315–400 NM): 1200 mW
INPUT VOLTAGE: 20-240 V AC, 50-60 HZ
DRIVER: 30 W, 220-240 V AC, integrated
INPUT POWER: 30 W (±5%)
Footprint: 1.2 x 0.6 m
APPLICATION: Multi-layer, room, tent
WATERPROOF & DUSTPROOF: IP65
LIFESPAN: L90 > 8500 hrs
LIGHT DISTRIBUTION: 140°
LIGHT SOURCE: UV-B and UV-A household diodes
TOTAL NUMBER OF DIODES: 8 UV-B, 40 UV-A
DIMMABLE: No
EXTERNAL CONTROL: No
DAISY CHAIN ​​CAPABILITY: Yes
WEIGHT: 1.2 kg
DIMENSIONS: 1000 x 48 x 42 mm
HEAT MANAGEMENT: PASSIVE
POWER FACTOR: > 0.98
MAX. AMBIENT TEMPERATURE: 0 °C
BTU: 102 BTU/h
1 YEAR WARRANTY
CERTIFICATIONS: CE
